Guide on Working Principle of Thermal Overload Relay

A thermal overload relay is a safety device used in manual control circuits. The thermal overload shuts off the heating circuit using an electric motor to control its overheated short circuit when the temperature exceeds the specified threshold. The thermal overload relay will be used if there is a danger of a short circuit or if there are consistently high temperatures in the area where it is positioned.



A thermal overload relay is a type of relay used to guard against overheating in electrical circuits. To keep the motor going, it recognizes when the current has grown enough and opens rather than switching off the circuit's electricity.

A thermal overload relay has two contacts, one of which is often open and the other of which is typically closed, to effectively carry out its functions. In this article, the operation of a thermal overload relay will be described.



A relay for overload



An overload relay, a safety device, protects your circuit from damage caused by high-power loads. The relay opens to protect the circuit when the load reaches a certain threshold.



The simplest sort of overload relay switch is a single-pole, single-throw (SPST) switch. This type of relay only has one fixed position and responds to input signals from the load or source with a single step.

Before employing a relay, you must first be aware of the type of circuit you are protecting. For instance, it will be far safer to utilize a relay rather than a second tripping switch close to where the cook top cable links to the power cord if you have an electric stove top.



Consider a plug that has many circuits going through it. In that situation; you may also utilize overcurrent protection devices, such as overcurrent fuses or shutters, to safeguard certain circuits against harm brought on by an overload of current from other circuits coming into touch with them at the same time.



According to the concept of thermal expansion, the overload thermal relay is dragged out of the mounting base as it senses a temperature rise and expands. Push-on contacts that close when connections are withdrawn are therefore liberated.
